Palmer PGA04-8 Ohm

The integrated load resistor permits tube amplifiers up to approximately 120 W to be connected to the PGA04, bypassing a loudspeaker. A jack socket (unbalanced) and balanced XLR connector are available for direct pickup of the signal. The extensive filter section provides for a realistic simulation of classic guitar loudspeaker sounds.

Technical specifications:

• Loadbox: 6.3 mm jack input with parallel THRU socket for speaker operation Loadbox
• Input impedance: 8 ohms, max.
• Input load: 120 w RMS
• Input level display: 6 LED's
• Output: 2 x 6.3 mm jack, unbalanced, floating ground, 1 x balanced XLR output
• Output impedance: jack: 10.000 ohms, XLR: 600 ohms
• Level: unbalanced 0 dB, balanced -10 dB at 25 w
• Input Controls: Volume FiIlter, LOW, HIGH, LITE/BROWN-switch for tone shaping
• Full Range Volume for unfiltered signal, used in conjunction with the HI-CUT to emulate the bright sound of, e.g., 10-inch speakers

Both signals attenuable
